Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70 & 125, TRX125 Repair Manual 1970-1987

SKU: M311

Customer Rating: 1 Review(s) | Write a Review

Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70, 125, TRX125 ATV Repair Manual 1970-1987
Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70, 125, TRX125 ATV Repair Manual 1970-1987
MSRP: $39.95
Only $34.85
Free Shipping (US48)
In Stock
Item #: M311
-
+
Usually ships the next business day
Why Buy From Us?
  • Free Shipping
  • Veteran Owned
  • Secure Shopping
  • Satisfaction Guaranteed
Item Description

- GOING OUT OF PRINT - LIMITED QUANTITY -

The Clymer 1970-1987 Honda ATC, TRX, Fourtrax 70-125 covers the following ATV models:

  • Honda ATC70, 1973-1974, 1978-1985
  • Honda ATC90, 1970-1978
  • Honda ATC110, 1979-1985
  • Honda Fourtrax 70, 1986-1987
  • Honda ATC125M, 1984-1985
  • Honda TRX125, 1985
  • Honda Fourtrax 125, 1986

Book Excerpt: 1970-1987 Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70 and 125, TRX125 Repair Manual

CLUTCH AND TRANSMISSION

CLUTCH RELEASE MECHANISM

The clutch release mechanism is located within the right-hand crankcase cover (Figure 58).

  1. Drain the engine oil as described in Chapter Three.
  2. Remove the bolts securing the right-hand crankcase cover and remove the cover and the gasket. Don't lose the locating dowels.
  3. From the exterior of the crankcase cover, remove the locknut and washer from the adjuster screw.
  4. Within the right-hand crankcase cover, remove the adjuster screw and the O-ring seal.
  5. Install by reversing these removal steps, noting the following.
  6. Refill the engine with the recommended type and quantity of engine oil; refer to Chapter Three.
  7. Adjust the clutch as described in Chapter Three.
EXTERNAL SHIFT MECHANISM

The external shift mechanism is located on the right-hand side of the engine, under the crankcase cover and next to the clutch assembly.

The mechanism can be removed with the engine in the frame.

To remove the shift drum and shift forks it is necessary to remove the engine and split the crankcase. This procedure is covered under Shift Drum and Shift Forks in this chapter.


CHAPTER SEVEN | ELECTRICAL SYSTEM
This chapter contains operating principles and service and test procedures for all electrical and ignition components. Information on the battery and spark plugs is covered in Chapter Three.

The electrical system includes the following systems:

  1. Charging system (models with a battery).
  2. Ignition system.
  3. Starting system (models so equipped).
  4. Lighting system.
Table 1-4 are at the end of this chapter. Wiring diagrams are at the end of the book.

CHARGING SYSTEM (MODELS SO EQUIPPED)

The charging system consists of the battery, alternator and a solid-state voltage regulator/ rectifier. Figure 1 shows a typical charging system.

Alternating current generated by the alternator is rectified to direct current. The voltage regulator maintains the voltage to the electrical load (lights, ignition, etc.) at a constant voltage regardless of variations in engine speed and load.


Subject: 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987 Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70, Fourtrax 125, TRX125 service, maintenance, repair. ISBN-10: 0892872144 | ISBN-13: 9780892872145 | Clymer M311

Specifications
  • Publisher: Clymer Series / Haynes Manuals
  • Pages: 350 - Hundreds of b&w photos and illustrations
  • Binding: Paperback - 7 x 10 inches
  • ISBN: 978-0-89287-214-5
  • Years: 1970 - 1987
Table of Contents
TABLE of CONTENTS:
  • General Information
  • Troubleshooting
  • Lubrication, Maintenance and Tune-up
  • Engine
  • Clutch and External Gearshift Linkage
  • Transmission and Internal Shift Mechanism
  • Fuel and Emission Systems
  • Exhaust System
  • Electrical System
  • Wheels, Tires and Drive Chain
  • Front Suspension and Steering
  • Rear Suspension
  • Brakes
  • Body and Frame
  • Wiring Diagrams
Questions & Answers about Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70, 125, TRX125 ATV Repair Manual 1970-1987

Questions & Answers about Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70, 125, TRX125 ATV Repair Manual 1970-1987

Ask a question about Honda ATC70, ATC90, ATC110, ATC125, Fourtrax 70, 125, TRX125 ATV Repair Manual 1970-1987.
Customer Reviews

REVIEWS

David verified customerOctober 1, 2016
honda ATV Repair Manual 1970-1987
Was trouble shooting why my engine would not start it did not say or tell me what to look for. But I found out what was wrong and got it started. It will help me if I have more things to fix !!!!!!!!!!
Was this rating helpful to you?   👍 Yes    👎 No
Click here to review this product
(Reviews are subject to approval)
