Yamaha RD400 Twins Repair Manual 1975-1979

SKU: HYM333-979

Customer Rating: 1 Review(s) | Write a Review

Yamaha RD400 Twin Repair Workshop Manual 1975-1979
Yamaha RD400 Twin Repair Workshop Manual 1975-1979
MSRP: $39.95
Only $34.85
Free Shipping (US48)
In Stock
Item #: HYM333-979
-
+
Usually ships the next business day
Why Buy From Us?
  • Free Shipping
  • Veteran Owned
  • Secure Shopping
  • Satisfaction Guaranteed
Item Description

The 1975-1979 Yamaha RD400 Twins repair manual by Haynes covers the following RD models:

  • Yamaha RD400 398cc, U.S.A. 1975, U.K. 1976
  • Yamaha RD400E 398cc, U.K. 1978

Book Excerpt: 1975-1979 Yamaha RD400 Twin Repair and Service Manual

FUEL SYSTEM AND LUBRICATION

SYNCHRONIZING TWIN CARBURETORS
  1. For optimum performance and even running, it is important that both carburetors are in phase, so that they open and close together and have the same settings throughout the entire throttle range.

    If this type of check is not carried out at regular intervals, one cylinder may do all the work, while 'carrying' the other.

    The usual symptoms of poor balance between the two carburetors are difficulty in starting and uneven running at low speeds, accompanied by a noticeable lag when accelerating.

  2. To check whether the carburetors are correctly synchronized, remove the aligning orifice plug from the right-hand side of each carburetor and open the throttle fully.

    By viewing through the aperatures, check that the lower edge of the aligning marks on the throttle valves align exactly with the lower edge of each aperature.

  3. If alignment is incorrect adjust each carburetor independently by means of the cable adjuster in each carburetor top. Finally, replace the orifice plugs.
  4. Remove the plug cap from the left-hand spark plug and start the engine. Screw in (clockwise) the throttle stop screw of the right-hand carburetor until the engine will continue to run on one cylinder at a reasonably low speed.

    Check whether adjustment of the pilot screw from the recommended setting of one and a half complete turns out has any noticeable effect on even running and readjust the throttle stop screw as necessary. Stop the engine.

  5. Repeat the above operation with the right-hand spark plug cap removed and adjust the left-hand carburetor. Stop the engine when the adjustment seems correct. Each cylinder should run independently at the same speed.
  6. Re-start the engine with both plug caps connected. Most probably the tick-over will now be too fast, in which case the throttle stop screws of each carburetor can now be screwed out an equal amount (a little at a time) until the desired engine speed is attained.

    Normally this is in the region of 1300 to 1400 rpm, as indicated by the tachometer.


WHEELS, BRAKES AND TIRES
BLEEDING THE HYDRAULIC SYSTEM
  1. As mentioned earlier, brake action is impaired or even rendered inoperative if air is introduced into the hydraulic system. This can occur if the seals leak, the reservoir is allowed to run dry or if the system is drained prior to the dismantling of any component part of the system.

    Even when the system is refilled with hydraulic fluid, air pockets will remain and because air will compress, the hydraulic action is lost.

  2. Check the fluid content of the reservoir and fill almost to the top. Remember that hydraulic brake fluid is an excellent paint stripper, so beware of spillage, especially near the gas tank.
  3. Place a clean glass jar below the brake caliper unit and attach a clear plastic tube from the caliper bleed screw to the container. Place some clean hydraulic fluid in the container so that the pipe is always immersed below the surface of the fluid.
  4. Unscrew the bleed screw one complete turn and pump the handlebar lever slowly. As the fluid is ejected from the bleed screw the level in the reservoir will fall. Take care that the level does not drop too low while the operation continues, otherwise air will re-enter the system, necessitating a fresh start.

Subject: Transportation: Motorcycles: Yamaha 1975, 1976, 1977, 1978, 1979 RD400 Twin service, maintenance, tuneup and repair. ISBN-10: 0856965480 | ISBN-13: 9780856965487 | Haynes 333

Specifications
  • Publisher: Haynes Manuals
  • Pages: 128 - Over 325 b&w photos and illustrations
  • Binding: Paperback - 8.5 x 11 inches
  • ISBN: 978-0-85696-548-7
  • Years: 1975 - 1979
Table of Contents
TABLE of CONTENTS:
  • Maintenance
  • Engine, clutch and transmission
  • Fuel system and lubrication
  • Ignition system
  • Frame and forks
  • Wheels, brakes and tires
  • Electrical system
  • Wiring diagrams
Questions & Answers about Yamaha RD400 Twin Repair Workshop Manual 1975-1979

Questions & Answers about Yamaha RD400 Twin Repair Workshop Manual 1975-1979

Ask a question about Yamaha RD400 Twin Repair Workshop Manual 1975-1979.
Customer Reviews

REVIEWS

bigdavet verified customerDecember 18, 2017
Haynes RD400 Manual
While it's always nice to have a shop manual dedicated to your particular machine, the Haynes leaves a lot to be desired. Not only is it written in "British English," but the photos are horrendous. You can't even see detail in them. It's better than nothing, but I'll buy a different brand the next time I'm in the market.
Was this rating helpful to you?   👍 Yes    👎 No
Click here to review this product
(Reviews are subject to approval)
