Book Excerpt: 1994-2001 Yamaha YZ125 Repair Manual TROUBLESHOOTING
TWO-STROKE LEAK DOWN TEST Many owners of two-stroke bikes are plagued by hard starting and generally poor running, for which there seems to be no cause. Carburetion and ignition may be good, and compression tests may show that the engine's upper end is satisfactory. What a compression test does not show is lack of primary compression. The crankcase in a two-stroke engine must be alternately under pressure and vacuum. After the piston closes the intake port, further downward movement of the piston causes the entrapped mixture to be pressurized so it can rush quickly into the cylinder when the scavenging ports are opened. Upward piston movement creates a slight vacuum in the crankcase, enabling the air/fuel mixture to be drawn in from the carburetor.
CAPACITOR DISCHARGE IGNITION
CDI CAUTIONS When servicing the CDI system, note the following:
The CDI unit is a sealed unit. Do not attempt to open it, as this causes permanent damage.
- Keep all connections between the various units clean and tight. Be sure that the wiring connectors are pushed and locked together firmly (Figure 2).
- Never disconnect any of the electrical connections while the engine is running. Otherwise, excessive voltage may damage the coils or the igniter unit.
- When kicking the engine over with the spark plug removed, make sure the spark plug is installed in the plug cap and grounded against the cylinder head (Figure 3). If not, excessive resistance may damage the igniter unit.
- The CDI unit is installed in a rubber vibration isolator. Make sure that the CDI unit is installed correctly. Handle the CDI unit carefully when removing and installing it from the frame.
Subject: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001 Yamaha YZ125 service, maintenance, repair. ISBN-10: 0892878398 | ISBN-13: 9780892878390 | Clymer M497-2
- General Information
- Lubrication, Maintenance and Tune-up
- Clutch and External Gearshift Linkage
- Transmission and Internal Shift Mechanism
- Fuel and Emission Systems
- Exhaust System
- Electrical System
- Wheels, Tires and Drivetrain
- Front Suspension and Steering
- Rear Suspension
- Body and Frame
- Wiring Diagrams
Above: Ted Abear of Ironton, Minnesota began riding dirt bikes after buying his 2001 Yamaha YZ125 from a family friend. He usually rides locally, but since trying a few motocross races in 2010, the bug bit him and he's now hooked and plans to enter many more cross races in the future.
