Johnson Outboards Repair Manual 3.5-250 HP, 2-Stroke, 4-Stroke Models 2002-2007Click To Enlarge Product Image

Johnson Outboards Repair Manual 3.5-250 HP, 2-Stroke, 4-Stroke Models 2002-2007

Item #SE1314
MSRP: $36.95
$27.95
(You Save $9.00)
QTY:
Usually ships the next business day
Safe ShoppingEasy Returns
Free Ground Shipping
  • Item Description
  • Table of Contents
  • Specifications

This repair and service manual covers Johnson outboard engines (all models) 3.5-250 HP, 2- and 4-stroke, 2002-2007.

Step-by-step illustrated keyed procedures guide you through every conceivable job possible, including all adjustments necessary. Perfect for do-it-yourselfers, professional mechanics, or students.


Book Excerpt: 2002-2007 Johnson Outboards Repair Manual 3.5-250 HP, 2-Stroke, 4-Stroke Models

LUBRICATION AND COOLING

OIL METERING SYSTEM (OMS) - 2-STROKE MOTORS

Unlike 4-stroke engines, which contain a reservoir of oil that is recirculated during engine operation, mixing oil with the fuel lubricates 2-stroke engines. Internal engine components of 2-stroke motors are lubricated as the fuel/oil mixture passes through the crankcase and the cylinder.

Generally speaking, there are 2 methods of adding oil to a 2-stroke outboard. The first is to pre-mix oil with the gasoline whenever the fuel tank is filled. The pre-mix method is generally used on smaller (lower horsepower) motors and on most commercial outboards. It is easiest to perform this on portable fuel tanks that can be agitated to ensure proper mixture, but it can be successfully accomplished on larger built-in tanks, as long as care is taken to properly measure the amounts of fuel/oil being added.


SPECIAL TOOLS
See Figure 57

Almost every marine engine around today requires at least one special tool to perform a certain task. In most cases, these tools are specially designed to overcome some unique problem or to fit some oddly sized component.

When manufacturers go through the trouble of making a special tool, it is usually necessary to use it to ensure that the job will be done right. A special tool might be designed to make a job easier, or it might be used to keep you from damaging or breaking a part.

Don't worry, MOST maintenance procedures can either be performed without any special tools OR, because the tools must be used for such basic things, they are commonly available for a reasonable price. It is usually just the low production, highly specialized tools (like a super thin 7-point star-shaped socket capable of 150 ft. lbs. (203 Nm) of torque that is used only on the crankshaft nut of the limited production what-dya-callit engine) that tend to be outrageously expensive and hard to find. Hopefully, you will probably never need such a tool.


Subject: 2002, 2003, 2004, 2005, 2006, 2007 Johnson Outboard 3.5-250 HP, 2-Stroke, 4-Stroke Models service, maintenance, repair. ISBN-10: 0893300721 | ISBN-13: 9780893300722 | Seloc 1314

TABLE of CONTENTS:

  • General information
  • Tools and equipment
  • Boating safety
  • Engine tune-up
  • Engine disassembly and reassembly
  • Fuel system
  • Ignition system
  • Electrical system
  • Cooling system
  • Powerhead
  • Lower unit
  • Tilt and trim
  • Hand rewind starter
  • Engine specs; torque specs
  • Maintenance and off-season storage
  • Wiring diagrams

  • Publisher: Seloc Publishing
  • Pages: 388 - Hundreds of b&w photos and illustrations
  • Binding: Paperback - 8.5 x 11 inches
  • ISBN: 978-0-89330-072-2
  • Years: 2002 - 2007
  • Questions & Answers about Johnson Outboards Repair Manual 3.5-250 HP, 2-Stroke, 4-Stroke Models 2002-2007

    Ask a question about Johnson Outboards Repair Manual 3.5-250 HP, 2-Stroke, 4-Stroke Models 2002-2007. Click here
