Honda VF500, Magna, Interceptor Repair & Service Manual 1984-1986

SKU: M329
Honda VF500, Magna, Interceptor Repair Manual 1984-1986
Honda VF500, Magna, Interceptor Repair Manual 1984-1986
MSRP: $39.95
Only $34.85
Free Shipping (US48)
In Stock
Item #: M329
-
+
Usually ships the next business day
Why Buy From Us?
  • Free Shipping
  • Veteran Owned
  • Secure Shopping
  • Satisfaction Guaranteed
Item Description

The 1984-1986 Honda VF500, Magna, Interceptor sportbike repair manual by Clymer covers the following motorcycle models:

  • Honda VF500C Magna V-30
  • Honda VF500F Interceptor

Book Excerpt: 1984-1986 Honda VF500, Magna, Interceptor Repair Manual

FUEL, EXHAUST AND EMISSION CONTROL SYSTEMS

THROTTLE CABLE REPLACEMENT
  1. Remove the seat as described in Chapter Twelve.
  2. Remove the fuel tank as described in this chapter.
  3. On Interceptor models, remove the front fairing as described in Chapter Twelve.
  4. Remove the air filter case as described in this chapter.
  5. Disconnect the front brake light switch electrical connectors (A, Figure 42).
  6. Remove the screws securing the right-hand switch/throttle housing halves together (B, Figure 42).
  7. Remove the housing from the handlebar and disengage the throttle cables (C, Figure 42) from the throttle grip.
  8. Partially remove the carburetor assembly, as described in this chapter, until it is easy to gain access to the throttle cable attachment points.

IGNITION TIMING
Honda V-Fours are equipped with a capacitor discharge ignition system (CDI). This system uses no breaker points and is non-adjustable. The timing should be checked to make sure all ignition components are operating correctly.

Incorrect ignition timing can cause a drastic loss of engine performance and efficiency. It may also cause overheating.

Before starting on this procedure, check all electrical connections related to the ignition system. Make sure all connections are tight and free of corrosion and that all ground connections are tight.


Subject: 1984, 1985, 1986 Honda VF500, Magna, Interceptor service, maintenance, repair. ISBN-10: 0892874198 | ISBN-13: 9780892874194 | Clymer M329

Specifications
  • Publisher: Clymer Series / Haynes Manuals
  • Pages: 352 - Hundreds of b&w photos and illustrations
  • Binding: Paperback - 7 x 10 inches
  • ISBN: 978-0-89287-419-4
  • Years: 1984 - 1986
Table of Contents
TABLE of CONTENTS:
  • Quick Reference Data
  • General Information
  • Troubleshooting
  • Lubrication, Maintenance and Tune-up
  • Engine
  • Clutch and Transmission
  • Fuel and Exhaust Systems
  • Ignition System
  • Front Suspension and Steering
  • Rear Suspension
  • Brakes
  • Body and Frame
  • Wiring Diagrams
