This repair manual covers 1988-2000 Honda TRX300 Fourtrax and TRX300FW Fourtrax 4x4 ATVs.
Want to extend your Honda All-Terrain Vehicle's life? Then don't neglect regular scheduled maintenance jobs such as oil and filter change, installing a fresh air-cleaner element, and replacing the spark plug as recommended by the manufacturer.
These simple tasks will help extend the life of your Honda four-wheeler considerably, they will help it run better and more efficiently. Plus, they are easy to perform by almost anyone as long as you have the right info by your side, and that's when the 1988-2000 Honda TRX300, TRX300FW 4x4 ATV repair manual by Clymer comes into play.
The Honda Fourtrax 300 1988 Manual covers 2000 Honda Fourtrax 4x4 maintenance and general information about every aspect of the engine, including background on the crankshaft, engine lubrication, how the oil pump delivers oil throughout the engine, the location of the clutch and the transmission, and so much more for DIY Fourtrax owners.
Packed with everything you'll need to know to maintain, service and even completely disassemble and rebuild the ATV's engine, this is the reference guide that you need as part of your toolbox.
Book Excerpt: 1988-2000 Honda TRX300 Fourtrax 300, TRX300FW 4x4 ATV Repair Manual
THE ENGINE: GENERAL INFORMATION
The engine is an air-cooled, 4-stroke, single cylinder engine with a single overhead camshaft. The crankshaft is supported by 2 main ball bearings in a vertically split crankcase.
The camshaft is chain-driven from the timing sprocket on the right-hand side of the crankshaft and operates rocker arms that are individually adjustable.
Engine lubrication is by wet sump with the oil pump located on the right-hand side of the engine next to the clutch.
The oil pump delivers oil under pressure throughout the engine and is driven by a gear on the crankshaft.
This chapter contains information for removal, inspection, service and reassembly of the engine.
Although the clutch and transmission are located within the engine, they are covered in Chapter Five and Chapter Six to simplify this material.
Subject: 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000 Honda TRX300 Fourtrax, TRX300FW Fourtrax 4x4 service, maintenance,
repair. ISBN-10: 0892876409 ISBN-13: 9780892876402 | Clymer M346-3
