The Hands On Vehicle Testing ReferenceClick To Enlarge Product Image
The Hands On Vehicle Testing ReferenceThe Hands On Vehicle Testing Reference

The "Hands On" Vehicle Testing Reference, Do it Yourself Auto/Truck Electrical Testing

Item #VES-1024
MSRP: $98.00
$68.95
(You Save $29.05)
QTY:
Usually ships the next business day
Safe ShoppingEasy Returns
Free Ground Shipping
  • Item Description
  • Table of Contents
  • Specifications

Automotive Electrical: Quick Tests, Short Cuts, Insight, Information, Advice and Encouragement From The "Auto Shop Teacher"

We need to do a quick check on our mass air flow sensor. This device is critical to managing mass air flow rates, ensuring the internal combustion engine operates efficiently. Without it, you can’t gauge the balance and delivery of fuel mass to the engine.

Here we go: Tap the sensor lightly. If the engine falters, there may be a problem.

???

Was it really that easy?

Well, no. It’s only the beginning. But it’s only because we have this excellent car and truck electrical system test book that we even know where to start. After all, how many of us have the slightest idea where to find the mass air flow sensor in the first place?

“The Hands On Vehicle Testing Reference” is a 580 page library of car and truck electrical system practices with photos and illustrations that will benefit the operations of any professional auto tech or garage do-it-yourselfer. Inside this book, you are going to find over 200 tests for everything from computer modules to circuit breakers.

The Content

This book is a world of quick tests, insights, shortcuts and info that you’ll constantly be reaching for. Set up like a spiral notebook, it’s a handy resource that can be easily left open while you work. Engineered to save time, each page is designed with clear text and illustrations for testing, and providing the background you need to understand and improve vehicular electrical and electronic systems.

Included are ways to test condensers and capacitors, rear window defroggers, primary and secondary resistance values, overheating radiators and much more. There is also a ton of car and truck electrical system troubleshooting tips for looking at radio interference, trailer wiring and seeing if there’s gasoline in a diesel fuel tank.

The Author

Joe Glassford has a combined 54 years as a teacher in automotive technology, electronics and electricity. He was not only the penultimate public school auto shop teacher. Glassford has also taught classes at Allen Test Products, Triton College, Delta Corporate Services and General Motors.


Subject: Automotive Electrical Handbook Reference (Tons of Outstanding / Proven Electrical Tips, Tricks & Strategies). | ISBN-10: 0692661026 | ISBN-13: 9780692661024 | Vested LLC 1024

Below: The Hands On Vehicle Testing Reference Sample Page. Copyright Vested LLC.
Auto/Truck Electrical Testing Sample Page - Test Window Defogger

Meters & Meter Information
16 How to Set 2 different Meters to Read All of the Following: Open Circuit Voltage, Charging Voltage, or Source Voltage.

18 How to Place the Meter Probes to Find Open Circuit, Charging, or Source Voltage.

20 How to Set the Meter to Read Source Voltage Available to Any Load on the Vehicle.

22 How to Place The Probes to Find The Amount of Source Voltage Available to Any Load on the Vehicle.

24 How to Set the Meter for Reading Voltage Drop Between the Battery Positive (+) Terminal and the Input Pin to Any Load.

26 How to Place Probes Voltage Dropping Between the Battery Positive (+) Terminal and the Input Pin to Any Load.

28 How to Extend Meter Leads When Testing a Long Distance From the Battery.

30 About Meter Selection.

31 Understanding a Meter’s MIN MAX Mode.

32 How to Get the Most Out of the MIN/MAX Setting on Your Meter.

33 How to Test The Resistance of Your Voltmeter Tests Leads.

34 How Accurate is Your Test Meter?

35 A Word About the .5% Accurate Meter.

36 How to Test the Accuracy of a Digital Voltmeter.

37 Does Your Meter Need to be “Calibrated”?

38 About Checking One Meter’s Reading Against Another.

39 When and Why You Should Change Your Meter’s Battery.

40 When To Push the “Hold” Button on a Digital Voltmeter.

40 When to Push the “HZ” (frequency) Button on a Digital Voltmeter.

41 What Can a Meter’s “Bar Graph” Tell You?

42 What You Need to be Aware of When Using an “Auto Range” Meter.

44 How to Use a Temperature Probe That Plugs Into a Voltmeter.

45 How Accurate Should Test Results Be?

45 About meter input impedance.

About Voltage & Voltage Drop Testing
46 Understanding What a Voltmeter is Reading.

49 What is Voltage?

50 What is Voltage Drop?

51 What Should You Check First Before Doing Voltage Drop Testing?

52 What Can Cause a Voltage Drop?

53 Don’t Overlook a Detailed Visual Inspection.

54 How Connections Affect Voltage Drop.

55 About the Blade to Female Terminal Connection “Drag Test”

56 About Terminal Connection “Fretting”.

59 How Connections Affect Voltage Drop.

60 How Heat Can Cause a Voltage Drop.

61 How DC “Motor Drag” Can Affect Voltage Drop.

62 Understanding “In-Rush” Current.

64 How DC Motor In-Rush Current Can Affect Voltage Drop.

65 About Wire Insulation Porosity and Voltage Drop.

66 How to Do Voltage Drop Testing With the EZ 3 Step. Meters & Meter Information About Voltage & Voltage Drop Testing

70 Understanding the Difference: "Voltage Available to the Input Pin/s of Any Load", and "Voltage Drop in the Current Path“.

75 About Ignoring Polarity When Looking For Voltage Drop.

76 About Voltage Drop Testing Polarity.

77 About Probe Placement When Voltage Drop Testing on the Voltage Feed Side.

79 The Importance of Correct Probe Placement When Looking for Voltage Drop.

82 About Using a Grounding Source Other Than The Battery Negative (-) Terminal.

84 If You Think any Grounding Point Will Do, Read This.

90 “Ball Park” Voltage Drop Standards.

91 How to do “Base System Testing”.

95 When the Testing Voltage is Exactly the Same as the Source Voltage.

96 When the Voltage Drop is Still Excessive After Repair, Then What?

Amp Testing with a Meter & Inductive Pick-up Use
97 How to Set a Meter to Read Amps.

98 How to Set a Meter to Read mA (milliamps) and µA (micro amps).

99 About Amp Draw Testing Probe Polarity.

100 How and Where To Use an Inductive Pick-up.

101 How to Get an Accurate Reading with an Inductive Pick Up.

102 How to Calibrate a “Rotating Knob” Inductive Pick-up Plugged Into a Voltmeter.

103 How to Calibrate a “Zero Button” Inductive Pick-Up Plugged into a Voltmeter.

104 About The Sensitivity of a Calibrated Meter.

106 How Accurate is the Current Clamp?

108 How to Read a 1 mV-per-amp Inductive Pick-up When a Voltmeter is Set to mV.

109 How to Read a 1 mV-per-amp Inductive Pick-up when a Voltmeter is set to Volts.

110 How to Read a 10mV/Amp Inductive Pick-up when a Voltmeter is set to mV.

111 How to Read a 10mV/Amp Inductive Pick-up When a Voltmeter is Set to Volts.

112 How to Read a 100mV/Amp Inductive Pick-up with a Voltmeter set to mV.

113 How to Read a 100mV/Amp Inductive Pick-up with a Voltmeter set to Volts.

114 About Inductive Pick-ups (Amp Clamps, Current Clamps, Current Probe).

115 About “Current Ramping”.

116 How to Adapt a Current Clamp (Amp Clamp, Current Probe) to an Oscilloscope.

117 How to Make and Use a 10X Inductive Multiplier.

Battery Testing
118 How to Test the Open Circuit Voltage of the Battery.

120 How to Test the Voltage Drop Between the Battery (+) or (-) Post and the Clamp.

122 How To Find The Voltage Drop Between: The Battery (+) Terminal and a Positive (+) Pigtail Attached to a Fuse Box or BEC.

124 How to Test the Voltage Drop of a Battery (+) Pigtail Wire Between the Battery (+) Terminal and a BEC.

125 How to Test the Voltage Drop of a Battery Positive (+) Pigtail Wire Between the Battery Positive (+) Terminal and a Fuse Box.

127 How to Test the Voltage Drop Between the Wire and the Clamp Material in a Battery (+) Cable or (+) Pigtail Wire.

129 How to Test the Voltage Drop Between: The Battery Negative (-) Terminal and Where the Negative (-) Cable Attaches.

131 How to Test the Voltage Drop Between the Battery Negative (-) Cable Conductor and its End Connectors.

133 How to Test the Voltage Drop Between the Battery (-) Terminal and Where a Battery (-) Pigtail Attaches.

135 How to Test the Voltage Drop Between the Battery Negative (-) Terminal and the Bulkhead Ground Strap.

137 How to Test the Voltage Drop Between the Bulkhead Ground Strap and the Block.

138 How to Test the Voltage Drop Between the Battery (-) Terminal and Ground Straps not Directly Attached to the Negative Cable.

140 Two More Ways to Test a Ground Strap Not Attached to the Battery Negative Cable.

144 How to do a Voltage Drop Test Between Truck Bed and Cab Sheet Metal.

146 How to Set the Meter to Read the Voltage Drop Between the Battery (-) Terminal and the Output Pin or Case Ground.

148 How To Place The Probes To Find Voltage Drop Between: The Battery (-) Terminal and The Output Pin or Case Ground.

150 How to Test the Voltage Drop on the Ground Side of a Case Grounded Module or Component.

151 How to Do a Battery Load Test Using a VAT 40 or 45.

153 How to Do a Battery Load Test Without a Load Tester.

154 How to Do a 3-Minute Charge Test on a Battery.

156 How and Where To Hook Up An Auxiliary Battery to Avoid Losing Computer Memory.

158 How to Test For a Shorted Battery in a 2 Battery System.

159 About “Parasitic Drain”.

160 Drain Times Until Battery Goes Dead.

161 How to Find The Battery’s Parasitic Drain on a Battery Using a Meter Set to Read mA.

163 How To Find The Battery’s Parasitic Drain Using a 1Ω /10watt Resistor In Series With Battery Post and Cable.

165 How to use the Kent-Moore J-38758 Parasitic Draw Test Switch.

167 How to Find the Battery’s Parasitic Drain by Reading the Voltage Drop Across a Fuse.

170 Can You Use an Inductive Pick Up to Find Parasitic Load?

172 How to See if The Battery Has Low Resistance That Could Cause Generator/Alternator Diodes to Burn Out.

174 How To Hook Up Battery “Jumper Cables”.

176 How to Neutralize Battery Acid.

177 How to Charge the Battery.

178 How a Battery Cable to Terminal Connection Can Cause a Voltage Drop That Can Cause Ring Gear Damage.

179 About the “Side Mount” Battery Cable Connections.

180 About Touching Removed Battery Cables Together to Clear Computer Memory.

181 About Scan Tool and Battery Charger Hooked Up at the Same Time.

181 About Scan Tools.

Computer Module & Sensor Testing
182 How to Test the Voltage Drop of Computer Voltage Feed Wires That Can Be Back-probed.

184 How to Test the Voltage Drop of Computer Ground Wires that Can Be Back-probed.

186 How to Load Test Computer Voltage Feed Wires That Cannot Be Back-probed.

188 How to Load Test Computer Ground Wires That Cannot Be Back-Probed.

190 Understanding the “Diode Test Mode” of a Digital Volt/Ohm/Amp Meter.

191 How to Test a Diode Removed From a Fuse Box or BEC (bussed electrical connector).

192 How to Test a Diode.

193 How to Test an LED (Light Emitting Diode) Using a Test Light.

194 How to Test an LED (Light Emitting Diode) with the Diode Test Mode of a Meter.

195 How to Test a NPN Transistor. Amp Testing with a Meter & Inductive Pick- Up Use

196 How to Test a PNP Transistor.

198 How to Test for a PCM (Power Train Control Module) Reset.

199 Things to Consider Before Re-flashing a Module.

201 Quick Test to See if the MAF (Mass Air Flow) Sensor is Your Problem.

202 How to Test for a Bad MAF (Mass Air Flow) Sensor with a Scan Tool.

203 How to Narrow Down Which Computer is Drawing an Excessive Amount of Current.

204 How to Use a “NOID” (Neon Organic Iodine Diode) Light.

203 How to Test the Resistance of a PM (Permanent Magnet) Generator.

206 How to Test a Knock Sensor.

207 Quick Test to See if a Hall Effect Switch is Working.

208 About Hall Effect Switches.

210 How to Test a Thermistor Temperature Sensor.

213 About Thermistor Temperature Sensors.

214 How to Test the Computer Sensor Reference Voltage.

216 How to Test for an Open Throttle Position Sensor With a Voltmeter.

217 How to Test a TPS (Throttle Position Sensor) with the Bar Graph on a Voltmeter.

218 How to Test a Throttle Position Sensor With an Oscilloscope.

219 How to Test a MAP (Manifold Absolute Pressure) Sensor With a Voltmeter and Vacuum Pump.

220 How to Measure Frequency of a MAP or Mass Air Flow Sensor.

221 How To Test a Carburetor MC (Mixture Control) Solenoid.

222 How to Convert Frequency and Duty Cycle Measurements to Pulse Width.

223 How to Find a Dead Oxygen Sensor With a Voltmeter.

225 How to Test the Voltage Drop on the Ground side of an Oxygen Sensor Signal.

226 How to Check for a Shorted Computer Controlled Solenoid or Relay.

227 Quick Test for Oxygen Sensor Response Time to Lean and Rich Air/Fuel Ratio.

228 How to Bench Test an Oxygen Sensor with a Propane Torch

230 No Meter Test for an Oxygen Sensor Heater Problem.

221 How to Test the Oxygen Sensor With an Analog Lab Scope.

232 The Case for Load Testing All Wires.

234 Before You Jump Into Any Type of Diagnosis on a Computer Controlled Vehicle, Revisit The Fundamentals.

235 What to Do Before You Replace a Computer or an Electronic Control Module.

236 About Welding on a Computer Controlled Vehicle.

237 About Diodes.

241 About Light Emitting Diodes (LED).

242 About Transistors.

243 About Basic Logic Gates.

246 About Computer/Module Logic Control.

251 How to do a Basic IC Chip Test on a Discrete Component Board.

252 About Resistors.

255 About (PM) Permanent Magnet Generators.

255 About the TPS (Throttle Position Sensor).

256 About “Pulse-Width Modulation”.

258 Understanding a “Signature Waveform”.

208 About Hall Effect Switches.

210 How to Test a Thermistor Temperature Sensor.

213 About Thermistor Temperature Sensors.

214 How to Test the Computer Sensor Reference Voltage.

216 How to Test for an Open Throttle Position Sensor With a Voltmeter.

217 How to Test a TPS (Throttle Position Sensor) with the Bar Graph on a Voltmeter.

218 How to Test a Throttle Position Sensor With an Oscilloscope.

219 How to Test a MAP (Manifold Absolute Pressure) Sensor With a Voltmeter and Vacuum Pump.

220 How to Measure Frequency of a MAP or Mass Air Flow Sensor.

221 How To Test a Carburetor MC (Mixture Control) Solenoid.

222 How to Convert Frequency and Duty Cycle Measurements to Pulse Width.

223 How to Find a Dead Oxygen Sensor With a Voltmeter.

225 How to Test the Voltage Drop on the Ground side of an Oxygen Sensor Signal.

226 How to Check for a Shorted Computer Controlled Solenoid or Relay.

227 Quick Test for Oxygen Sensor Response Time to Lean and Rich Air/Fuel Ratio.

228 How to Bench Test an Oxygen Sensor with a Propane Torch

230 No Meter Test for an Oxygen Sensor Heater Problem.

221 How to Test the Oxygen Sensor With an Analog Lab Scope.

232 The Case for Load Testing All Wires.

234 Before You Jump Into Any Type of Diagnosis on a Computer Controlled Vehicle, Revisit The Fundamentals.

235 What to Do Before You Replace a Computer or an Electronic Control Module.

236 About Welding on a Computer Controlled Vehicle.

237 About Diodes.

241 About Light Emitting Diodes (LED).

242 About Transistors.

243 About Basic Logic Gates.

246 About Computer/Module Logic Control.

251 How to do a Basic IC Chip Test on a Discrete Component Board.

252 About Resistors.

255 About (PM) Permanent Magnet Generators.

255 About the TPS (Throttle Position Sensor).

256 About “Pulse-Width Modulation”.

258 Understanding a “Signature Waveform”.

259 About “Sensors”.

261 About Oxygen Sensors.

264 About Oxygen Sensor Heater Control.

265 About Oxygen Sensor “Cross Counts”.

266 Ohm Meter Testing of Resistance Variable Sensors.

267 About Voltage Referenced, Resistance Variable Sensors.

268 About Voltage Referenced, Frequency Variable Sensors.

269 About Linear and Non-Linear Sensor Response.

271 About Temperature Coefficient Relative to Resistance.

272 How to Use a Digital Logic Probe.

274 How to Measure the Resistance of a Component (Circuit Load or Sensor).

275 How to Test the Resistance of a Resistor.

Continuity Testing & Ohmmeter Use
276 How To Do Continuity Testing With A DVOM (Digital Volt Ohm Meter) Set as an Ohmmeter.

277 How to Test for Continuity with a Test Light.

278 How to Read Accurate Resistance Values With or Without a Zero Button.

279 How to Test For Continuity in a Single Length of Wire With An Ohmmeter.

280 How To Tell if Solid State Components are Affecting Ohmmeter Resistance Readings.

281 How Your Body’s Resistance Can Interfere With an Ohmmeter’s Reading.

282 Why Continuity Testing is NOT Reliable.

283 Cautions When Using an Ohmmeter.

285 How Battery Cable Position, Key ON/OFF, and Engine Running Affect Ohmmeter Readings.

287 Understanding Static and Dynamic Resistance.

289 What Does Series and Parallel Resistance Have to do With Troubleshooting?

290 Floating Voltage Values (Ghost Voltage) and What They Mean.

296 How to Test for Available Voltage to a “Hot at All Times” or “Hot in Run & Start” Current Path.

299 How to Load Test a “Hot At All Times” and a “Hot In Start Or Run” Current Path.

300 How to find Both Ends of the Same Wire Buried in a Wire Loom with an Ohmmeter.

301 How to find Both Ends of the Same Wire Buried in a Wire Loom with a Voltmeter.

302 How to find Both Ends of the Same Wire Buried in a Wire Loom with a Self-Powered Test Light.

303 How to Test The Voltage Drop of any Length of Wire.

304 Quick Test For a “Suspect Connector”.

305 How to Test the Voltage Drop of a “Suspect Wire Connector”.

306 Importance of T-Pin or Acupuncture Probe Placement when Testing for a Bad Connection.

307 How to Test Any Mechanical Switch Contacts Using an Ohmmeter.

308 How to Find a Switch with Excessive Resistance Using a Voltage Drop Test.

312 Obvious and Not So Obvious Causes of Intermittent Circuit Problems.

313 How to Deal With an Electrical/Electronic Intermittent.

315 Suggestion for Looking for That Electrical/Electronic Intermittent.

316 How to Find an Intermittent Voltage Spike or Voltage Drop Out.

317 How to Test a Condenser/Capacitor With a Digital Ohmmeter.

318 How to Test a Condenser/Capacitor With an analog meter.

317 How to Troubleshoot a Ground “Splice Pack”.

321 How to Test a Rear Window Defogger Using a Test Light.

322 How to Test a Rear Window Defogger using a Voltmeter.

323 How to Test For a Good Voltage Feed With a Test Light.

324 How to Test For a Good Ground With a Test Light.

Current Paths, Shared Current Paths, Connections & Switch Contact Testing
325 Understanding the Difference Between a “Switched to Voltage” and a “Switched to Ground” Current Path.

326 Types of Faults That Can Develop in Any “Switched to Voltage” or “Switched to Ground” Current Path.

327 Understanding Shared Current Paths.

328 Importance of Shared Current Path Testing.

329 Examples of Shared Current Paths on the Voltage Feed Side.

330 Examples of Shared Current Paths on the Ground Side. 331 How Voltage Drops in Shared Current Paths can Affect Drive-ability.

332 What a Difference 300mV (.300V) Can Make In a “Shared Ground”!

333 About Switch Contacts Used in Current Paths.

335 About Coefficient of Expansion Related to Metal.

336 Inside a BEC-Bussed Electrical Center.

337 How to Test the Voltage Drop Between the Battery Positive (+) Terminal and the Bussed Electrical Center – BEC.

339 Where and How to Add New Circuits to a Vehicle.

340 How to Stop Electrical Switch Pop “Noise” in a Radio.

341 How to Avoid a “Cold Solder Joint”.

342 How to Use Heat Shrink to Seal a Soldered Wire Connection.

343 How to Make a Soldered Connection Without an Electric Soldering Iron.

344 How to Use a Jumper Wire.

345 Precautions to Observe Whenever a Vehicle Component is Unplugged.

346 Observed Amperage Draw Range of Loads on Various Vehicles.

347 About Wire.

348 About Brush Bounce, Spring Tension, Arcing and Radio Frequency Interference (RFI).

349 About “Twisted Pair Shielded Wire”.

350 How Components Fail.

351 About Piercing, Splicing, and Repair of Wire.

353 About the T-pins & Acupuncture Piercing Tools.

354 About Corroded Connectors Caused by Water Intrusion.

356 About Weather Pack Connectors.

357 How to Troubleshoot a Short to Ground.

360 How to use an Inductive Pickup to Locate a “Short to Ground” Wire.

361 How to Find a Short to Ground that Results in a Blown Fuse Using an Ohmmeter.

362 Understanding the Terms “Short to Copper”, “Turn to Turn”, and “Internal Short”.

363 Understanding “short to voltage”, “short to power”, “short to ground”, and “dead short”.

366 What might happen when two different current paths make electrical contact?

378 How to Troubleshoot a “Short to Voltage” / “Short to Power”.

Fuel, Fuel Pump, & Fuel Injector Testing
388 How to Locate a Bad Fuel Injector Without Disassembly.

389 How to Do a Bench Load Test on a Fuel Injector.

390 How to Find a Dead Fuel Injector in a Port Fuel Injected System.

391 How To Find a Dead Fuel Injector With a Mechanic’s Stethoscope.

392 About the Digital Logic Pulser.

393 How to do an Injector Flow Test with a Logic Pulser.

394 How To Check the Resistance of Any Fuel Injector.

396 How to Test for a “Shorted” Fuel Injector.

397 How to Test for a Fuel Injector’s Waveform.

400 About the “Signature Waveform”.

401 About Fuel Injectors.

402 How to Test the Fuel Pump on an EFI Vehicle with a Fuel Return System.

405 How to Test Fuel Pump Pressure Through All Ranges of Engine Operation With a Scan Tool.

406 How to Test the Amperage Draw of an Electric Fuel Pump.

408 How to Tell the Difference Between a Fuel Pump Pressure or Volume Problem.

409 Quick Test For Good Fuel Volume With a Scan Tool or Digital Volt Meter.

410 How To Find the Percent of Alcohol in Gasoline.

412 How to Find Out if There is Gasoline in a Diesel Fuel Tank.

413 About fuses.

414 Never Assume any Fuse is “Good” by Just Looking At It.

415 How to Use a Blown Fuse to Direct Your Troubleshooting.

416 How Air Space in a Current Path Causes Heat.

Fuses, Fusible Link & Circuit Breaker Testing
417 How To Test Fusible Link Wire.

418 How To Test a Fuse “In The Fuse Box” With a Voltmeter.

419 How To Test a Fuse “In The Fuse Box” With a 12Volt Test Light.

420 How to Test a Fuse “Removed From the Fuse Box” Using an Ohmmeter.

421 How to Test a Fuse “Removed from the Fuse Box” Using a Self Powered Test Light.

422 How to Test the Voltage Drop Across a AGC® , OES® Fuse Connection.

423 How to Test the Voltage Drop Across an ATC®/ATO®, Maxi®, or Mini® Fuse Connection.

425 How to Test a Suspect Circuit Breaker.

426 About the Type 1 Auto Reset Circuit Breaker.

427 About the Type 2 Modified Reset Circuit Breaker.

428 About the Type 3 Manual Reset Thermal Non-cycling Circuit Breakers.

429 About the Positive Temperature Coefficient (PTC) Circuit Breaker.

Generator / Alternator Testing
430 How to Quickly Find Out if the Alternator is Charging.

431 How to Test the Voltage Drop Between: the Generator Output and the Battery Positive (+) Terminal.

433 How to Test Connectors and Connections of the Generator/Alternator Positive (+) Pigtail Wire.

434 How To Test The Voltage Drop of The Generator Ground.

436 How to Test the Voltage Drop Between the Generator Housing and the Block.

438 How to Test the Generator/Alternator Charging Voltage.

441 How to Test an Alternator /Generator for Undercharge and Overcharge.

442 How to Test a 3 Phase Generator (Alternator) for AC Riding on DC.

444 How to Check for Bad Diodes in a Non-Computer-Controlled Generator (Alternator) Using the “Diode Test Mode”.

446 How to Test for Shorted Diodes in the Generator (Alternator) Using The “Micro amp (µA) Range” of the Meter.

448 How to Use a Compass to Help You Troubleshoot Generator Charging Problems.

449 How to Use a Lab Scope to Measure Ripple Voltage.

451 About Generator/Alternator Testing.

452 How to Test the Generator Rotor for Current Draw.

454 How to Polarize a Generator.

Miscellaneous Tests & Other Valuable Automotive Electrical Information
455 How to Find a “False Air” Leak Using Propane

456 How to Verify That the Crankcase Can Hold a Vacuum on a Carbureted or Throttle Body Fuel Injected Vehicle.

457 How to Verify That a Rough Idle on a Carbureted or Throttle Body Vehicle is Not Caused by “Blow By”.

458 How To Deal With Engine “Knock”, “Ping”, “Detona457 How to Test for a Bad Power Brake Booster.

460 Quick Test for Checking Excessive Timing Chain Slack on a Distributor Equipped Engine.

461 About the Manometer (Slack Tube).

462 About Troubleshooting Trailer Wiring.

465 Help Backing a Trailer onto a Hitch.

466 Open Circuit Voltage Testing Caution!

467 About the Teslite® - Open Circuit Voltage Tester.

468 Open Circuit Voltage Feed Side Testing with a Teslite®.

469 Open Circuit Voltage Ground Side Testing with a Teslite®.

470 Consider a Pyrometer/Thermometer.

471 About the Infrared Thermometer.

473 How to Use a Timing Light.

473 How to Use a Timing Light to Find a Misfire.

474 How to Test for a Bad Throw-Out Bearing.

475 How to Check the Engine’s Intake Manifold Vacuum Looking for a Vacuum Leak.

477 How to Do a “Dry and Wet” Compression Test.

479 How to Do a “Running Compression” Test.

481 About the “Relative Compression Test”.

483 How to do a Cylinder Power Balance Test.

484 How to Do a “Cylinder Leak Down” Test.

488 Quick Test to See if a Water Pump is Working as Designed. on Fluid in the Combustion Chamber.

489 How to Check For a “Blown Head Gasket” with a Radiator Pressure Tester.

490 How to Check For a “Blown Head Gasket” Using a Battery Powered CO Tester.

491 How to Check For a “Blown Head Gasket” With an Air Compressor.

492 How to Check For a “Blown Head Gasket” Looking for False Boiling.

493 How to Check For a “Blown Head Gasket” With a Gas Analyzer.

493 How to Check For a “Blown Head Gasket” With a Combustion Leak Tester.

494 How to Test for Coolant (water & antifreeze) in a Vehicle’s Oil.

495 How to Find a Leak in an Exhaust System Using Transmission.

496 How to Find a Leak in an Exhaust System Using a Shop Vacuum Blower.

496 How to Check for a Plugged Exhaust System Using a Removed O2 Sensor Hole.

497 How to Check Exhaust Back Pressure to See if the Catalytic Converter is Plugged.

498 How to Find the Source of Radio Frequency Interference (RFI) Noise in a Vehicle.

499 How to Tell if an Engine Hesitation is Loss of Spark or Loss of Fuel.

503 How to use the ST125 Spark Tester.

504 How to do a Cranking Coil Stress Test Without a ST-125 Spark Tester.

505 How to Test for Spark Plug Wire Carbon Tracking and a Leaking Spark Plug Boot.

506 How to Test For a Shorted Secondary Coil Winding.

507 About the Resistance of Spark Plug Wires.

508 How to Test the Primary Resistance Values of DIS Coils.

509 How to Test the Primary & Secondary Resistance Values of Oil Filled Coils.

510 How To Find a Misfiring Coil on a Coil-On-Plug “COP” System.

511 How to do a Comparative Resistance Test on a Distributor-less Ignition System.

512 How To Check For Radiator Overheat.

513 How and Where to Use a Mechanic’s Stethoscope.

514 How to Use a Compass to Help You Troubleshoot.

515 How to Diagnose Bad Ball Joints.

516 How to Diagnose a Bad Wheel Bearing.

517 How to Check for Acid Content In Coolant With a Voltage Drop Test.

518 How to Check for Water in Brake Fluid Using a Voltage Drop Test.

519 How to Find Volts, Amps, Ohms, and Watts.

520 Understanding the term “Bar”.

521 How to Deal With that “Chirping Belt”.

522 How to Inspect an Engine Belt Using a Timing Light.

523 Observed Wire Sizes Used In Vehicles.

524 Temperature Conversion Chart – Centigrade to Fahrenheit / Fahrenheit to Centigrade.

525 Where to Start When Dealing with a No Start due to a “No Crank”.

525 Where to Start When Dealing with a No Start but Engine does Crank.

526 Understanding the Relay Coil Winding “Control” Circuit and the “Load” Circuit.

527 How to Test the Voltage Drop of a Relay Contact.

528 How to Troubleshoot a Relay Controlled Circuit.

529 How To Test a Relay Coil Winding For Engineered Resistance Value.

530 How to Bench Test for a Relay’s Contact Resistance.

532 How to “Hot Wire” a Relay Coil For the “Click”.

533 How to Test a Relay With a Diode Across The Coil Winding.

535 About Relays with a Surge Suppression Diode.

537 How to Test a Relay With a Resistor Across The Coil Winding.

538 About Relays With a Resistor Across the Coil Windings.

539 How to Troubleshoot a Non-Computer Controlled Relay Circuit.

543 How to Load Test a Relay Coil Winding.

544 More About Relays.

545 About “Starter Solenoids” and “Continuous Duty Solenoids”.

546 How to Test the Cranking Voltage Available to the Starter Motor.

548 How to Find the Actual Voltage Drop Between: the Battery (+) Terminal and the Starter Motor Armature Lead.

550 How to Test the Voltage Drop of the Starter Motor Ground.

552 How to Test the Voltage Drop Between the Starter Housing and the Block.

554 How to Test the Voltage Drop of a Starter Mounted or Remote Mounted Solenoid.

556 Quick Test for Cranking, Charging Voltage Looking for Excessive Starter Amp Draw With No Inductive Pick-Up Using MIN/MAX.

558 How to do a Starter Motor Amperage Draw Test With an Inductive Pick Up Plugged Into a Digital Voltmeter.

560 How to do a Starter Motor Amp Draw Test with a VAT 40 or 45.

562 How to do a Starter Motor Amp Draw Test With a Load Tester That has a Voltmeter and Amp Meter, but No Inductive Pick Up.

563 Understanding “Starter Motor Heat Soak” Starts Cold, Once Hot - No Start.

564 A Suggestion for the Color Blind Using Wiring Diagrams.

564 Smokes Bad Only When First Started Cold, Once Running, No More Smoke?

565 Working Alone? Some Suggestions.

566 How to Deal with a Rusted or Seized, Brake Bleeder, Tapered Plug, Nut, etc.

567 How to Remove a Rusted Disc Brake Drum or Rotor.

568 In The Event Your Cell Phone Goes in The Hot Tub, or Your Scan Tool or Voltmeter Get Soaked

569 About Parts Removal and Replacement.

570 To Use a Torque Stick or Not.

571 General Rules for Allowable Voltage Drop in Vehicle Circuits.

573 Sources for Useful Information on Vehicle Understanding and Testing.

574. The author, Joe Glassford’s, experience.

  • Publisher: Vested LLC
  • Author: Joe Glassford
  • Pages: 580 - Hundreds of b&w photos and illustrations
  • Binding: Plastic Spiral Coil - 8.5 x 1.5 x 5.5 inches
  • ISBN: 978-0-69266-102-4
  • The Hands On Vehicle Testing Reference
    $68.95
